DA100 Series

Transformers for Digital Audio Data Transmission

KMP_DA100C_C07 Page 2 of 3

www.murata-ps.com/support

PACKAGE SPECIFICATIONS

MECHANICAL DIMENSIONS

RECOMMENDED FOOTPRINT DETAILS

6 Pin DIL

6 Pin SM

0.135±0.02

(3.44±0.50)

0.25

(6.35)

0.354

(9.0) Max.

0.375

(9.52) Max.

1

1

1

1

0.012 (0.30)

0.008 (0.20)

0.40

(10.16)

0.20

(5.08)

0.025 (0.63)

0.021 (0.53)

0.354

(9.0) Max.

0.375

(9.52) Max.

0.50

(12.70)

0.025 (0.63)

0.021 (0.53)

0.10

(2.54)

0.04

(0.90)

0.012 (0.30)

0.008 (0.20)

0.25

(6.35)

DA103MC

XYYWW

DA101C

XYYWW

1

3

6

4

1

3

6

4

2

5

Top View

Top View

Pin finish

Matte tin

Peak wave solder temperature

300˚C for 10 seconds

Peak reflow temperature

1 For further information, please visit www.murata-ps.com/rohs

2 For high temperature reflow parts see DA100J series datasheet.

0.10 (2.54)

0.10 (2.54)

Ø0.05 (1.20) +0.006 (0.15)

-0.000 (0.00)

0.45

(11.50)

0.10 (2.54)

0.04

(1.00)

0.06 (1.60)

6 Pin DIL

6 Pin SM

Unless otherwise stated all dimensions in inches (mm)

±0.01 (0.25). All pins on a 0.1 (2.54) pitch and within

±0.01 (0.25) of true position.

Unless otherwise stated all dimensions in inches (mm) ±0.01 (0.25).

All pins on a 0.1 (2.54) pitch and within ±0.01 (0.25) of true position.

Package Weight 0.93g Typ.

TUBE OUTLINE DIMENSIONS

0.023±0.005

(0.60±0.15)

0.16 (4.00)

0.22 (5.50)

0.43

(10.95)

0.51

(12.95)

0.15

(3.80)

0.62 (15.70)

Unless otherwise stated all

dimensions in inches (mm)

±0.01 (0.25).

Tube length: 18.3±0.08

(465±2).

Tube material: Antistatic coated

clear pvc.

0.10 (2.54)

0.10 (2.54)

Ø0.05 (1.20) +0.006 (0.15)

-0.000 (0.00)

0.45

(11.50)

0.10 (2.54)

0.04

(1.00)

0.06 (1.60)
