AD8145

Rev. A | Page 12 of 24

2.0

–2.0

TIME (ns)

1.6

1.2

0.8

0.4

–0.4

–0.8

–1.2

–1.6

0.5

–0.5

0.4

0.3

0.2

0.1

–0.1

–0.2

–0.3

–0.4

1015202530354045

ERROR

OUTPUT

INPUT

Figure 22. Settling Time

–50

–80

0.1

100

FREQUENCY (MHz)

110

–55

–60

–65

–70

–75

VS = ±5V

VS = +5V

VOUT = 2V p-p

Figure 23. Second Harmonic Distortion vs. Frequency and Power Supplies,

VOUT = 2 V p-p, G = 1

–50

–80

0.1

100

FREQUENCY (MHz)

110

–55

–60

–65

–70

–75

VOUT = 2V p-p

VS = +5V

VS = ±5V

Figure 24. Second Harmonic Distortion vs. Frequency and Power Supplies,

VOUT = 2 V p-p, G = 2

4500

OUTPUT VOLTAGE (V p-p)

4000

3500

3000

2500

2000

1500

1000

500

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

NEGATIVE

SLEW RATE

POSITIVE

SLEW RATE

Figure 25. Slew Rate vs. Output Voltage Swing

–50

–120

0.1

100

FREQUENCY (MHz)

110

VOUT = 2V p-p

–60

–70

–80

–90

–100

–110

VS = +5V

VS = ±5V

Figure 26. Third Harmonic Distortion vs. Frequency and Power Supplies,

VOUT = 2 V p-p, G = 1

–50

–120

0.1

100

FREQUENCY (MHz)

110

VOUT = 2V p-p

–60

–70

–80

–90

–100

–110

VS = +5V

VS = ±5V

Figure 27. Third Harmonic Distortion vs. Frequency and Power Supplies,

VOUT = 2 V p-p, G = 2
