CC2500

SWRS040C

Page 74 of 89

0x1A: BSCFG – Bit Synchronization Configuration

Bit

Field Name

Reset

R/W

Description

7:6

BS_PRE_KI[1:0]

1 (01)

R/W

The clock recovery feedback loop integral gain to be used before a

sync word is detected (used to correct offsets in data rate):

Setting

Clock recovery loop integral gain before sync word

0 (00)

1 (01)

2KI

2 (10)

3KI

3 (11)

4KI

5:4

BS_PRE_KP[1:0]

2 (10)

R/W

The clock recovery feedback loop proportional gain to be used

before a sync word is detected.

Setting

Clock recovery loop proportional gain before sync word

0 (00)

1 (01)

2KP

2 (10)

3KP

3 (11)

4KP

BS_POST_KI

R/W

The clock recovery feedback loop integral gain to be used after a

sync word is detected.

Setting

Clock recovery loop integral gain after sync word

Same as BS_PRE_KI

KI /2

BS_POST_KP

R/W

The clock recovery feedback loop proportional gain to be used after

a sync word is detected.

Setting

Clock recovery loop proportional gain after sync word

Same as BS_PRE_KP

1:0

BS_LIMIT[1:0]

0 (00)

R/W

The saturation point for the data rate offset compensation algorithm:

Setting

Data rate offset saturation (max data rate difference)

0 (00)

±0 (No data rate offset compensation performed)

1 (01)

±3.125% data rate offset

2 (10)

±6.25% data rate offset

3 (11)

±12.5% data rate offset
