LMV331-N, LMV339-N, LMV393-N

www.ti.com

SNOS018G – AUGUST 1999 – REVISED FEBRUARY 2013

Absolute Maximum Ratings

(1) (2)

ESD Tolerance (3)

Human Body Model

LMV331-N/393-N/339-N

800V

Machine Model

LMV331-N/339-N/393-N

120V

Differential Input Voltage

±Supply Voltage

Voltage on any pin

5.5V

(referred to V− pin)

Soldering Information

Infrared or Convection (20 sec)

235°C

Storage Temp. Range

−65°C to +150°C

Junction Temperature (4)

150°C

(1)

Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for

which the device is intended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test

conditions, see the Electrical characteristics.

(2)

If Military/Aerospace specified devices are required, please contact the Texas Instruments Sales Office / Distributors for

availability and specifications.

(3)

Human Body Model, applicable std. MIL-STD-883, Method 3015.7. Machine Model, applicable std. JESD22-A115-A (ESD MM std. of

JEDEC)Field-Induced Charge-Device Model, applicable std. JESD22-C101-C (ESD FICDM std. of JEDEC).

(4)

The maximum power dissipation is a function of TJ(MAX), θJA. The maximum allowable power dissipation at any ambient temperature is

PD = (TJ(MAX) - TA)/θJA. All numbers apply for packages soldered directly onto a PC board.

Operating Ratings

(1)

Supply Voltage

2.7V to 5.0V

Temperature Range (2)

LMV393-N. LMV339-N, LMV331-N

−40°C to +85°C

Thermal Resistance (

θJA)

5-Pin SC70

478°C/W

5-Pin SOT23

265°C/W

8-Pin SOIC

190°C/W

8-Pin VSSOP

235°C/W

14-Pin SOIC

145°C/W

14-Pin TSSOP

155°C/W

(1)

Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for

which the device is intended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test

conditions, see the Electrical characteristics.

(2)

The maximum power dissipation is a function of TJ(MAX), θJA. The maximum allowable power dissipation at any ambient temperature is

PD = (TJ(MAX) - TA)/θJA. All numbers apply for packages soldered directly onto a PC board.

2.7V DC Electrical Characteristics

Unless otherwise specified, all limits guaranteed for TJ = 25°C, V

+ = 2.7V, V− = 0V. Boldface limits apply at the temperature

extremes.

Symbol

Parameter

Conditions

Min

Typ

Max

Units

(1)

(2)

(1)

VOS

Input Offset Voltage

1.7

TCVOS

Input Offset Voltage Average Drift

µV/°C

Input Bias Current

250

400

IOS

Input Offset Current

150

(1)

All limits are guaranteed by testing or statistical analysis.

(2)

Typical values represent the most likely parametric norm as determined at the time of characterization. Actual typical values may vary

over time and will also depend on the application and configuration. The typical values are not tested and are not guaranteed on

shipped production material.

Submit Documentation Feedback

Product Folder Links: LMV331-N LMV339-N LMV393-N
