CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS

CF

series

Chip Type, Standard

Specifications

Temperature Characteristics

(Max.Impedance Ratio)

Category Temperature Range

Rated Voltage Range

Rated Capacitance Range

Capacitance Tolerance

Tangent of loss angle (tan

δ)

ESR (1)

Leakage Current (

2)

Performance Characteristics

Item

– 55 to +105°C

2.5 to 25V

3.3 to 1500µF

± 20%

at 120Hz, 20°C

Less than or equal to the specified value at 120Hz, 20°C

Less than or equal to the specified value at 100kHz, 20°C

Less than or equal to the specified value.

After 2 minutes' application of rated voltage at 20°C

Z+105°C / Z+20°C

1.25

(100kHz)

Z

– 55°C / Z+20°C

1.25

Endurance

Damp Heat

(Steady State)

Resistance to

Soldering Heat

Marking

The specifications listed at right shall be met when the

capacitors are restored to 20°C after the rated voltage is

applied for 2000 hours at 105°C

The specifications listed at right shall be met when the

capacitors are restored to 20°C after the rated voltage is

applied for 1000 hours at 60°C, 90% RH.

After soldering the capacitor under the soldering conditions

prescribed here, the capacitor shall meet the specifications listed

at right, provided that it's temperature profile is measured at the

capacitor top and the terminal.

Pre-heating shall be done at 150 to 200°C and for 60 to 180 sec.

The duration for over +230°C temperature at capacitor surface

shall not exceed 60 seconds.

In the case of peak temp, less than 250°C, reflow soldering shall

be two times maximum.

In the case of peak temp, less than 260°C, reflow soldering shall

be once.

Measurement for solder temperature profile shall be made at the

capacitor top and the terminal.

Navy blue print on the case top

Capacitance change

tan

δ

Leakage current (

2)

Within ± 20% of the initial capacitance value (

3)

150% or less than the initial specified value

150% or less than the initial specified value

Less than or equal to the initial specified value

Capacitance change

tan

δ

Leakage current (

2)

Within ± 20% of the initial capacitance value (

3)

150% or less than the initial specified value

150% or less than the initial specified value

Less than or equal to the initial specified value

Capacitance change

tan

δ

Leakage current (

2)

Within ± 10% of the initial capacitance value (

3)

130% or less than the initial specified value

130% or less than the initial specified value

Less than or equal to the initial specified value

Low ESR, High ripple current.

Load life of 2000 hours at 105°C.

SMD type : Lead free reflow soldering condition at 260°C

peak correspondence.

Compliant to the RoHS directive (2011/65/EU).

1 ESR should be measured at both of the terminal ends closest where the terminals protrude through the plastic platform.

2 Conditioning : If any doubt arises, measure the leakage current after the voltage treatment of applying DC rated voltage continuously to the capacitor for 120

minutes at 105°C.

3 Initial value : The value before test of examination of resistance to soldering.

φD

4 to 6.3

（5.5L）

5 to 10

（L

6

）

Code

GB

GS

P

1

C

2

F

3

0

4

J

5

1

6

5

7

1

8

M

9

C

10

L

11

1

12

G

13

S

14

Configuration

Taping code

Size code

Capacitance tolerance (

±20%)

Rated capacitance (150

µF)

Rated voltage (6.3V)

Series name

Type

H

0.3 MAX.

C

±0.2

L

Series

Voltage ( j:6.3v )

Plastic platform

Lot No.

Capacitance

Negative

Positive

+0.1

-0.4

Dimensions

Type numbering system (Example : 6.3V 150µF)

Voltage

V

2.5

4

6.3

10

16

20

25

Code

e

g

j

A

C

D

E

Size

φD

L

A

B

C

E

H

φ4

4.0

5.4

5.0

4.3

4.3

1.0

0.5 to 0.8

φ5

5.0

5.9

6.0

5.3

5.3

1.6

0.5 to 0.8

φ6.3

6.3

5.4

7.3

6.6

6.6

2.1

0.5 to 0.8

φ6.3

6.3

5.9

7.3

6.6

6.6

2.1

0.5 to 0.8

φ8

8.0

6.9

9.0

8.3

8.3

3.2

0.8 to 1.1

φ8

8.0

11.9

9.0

8.3

8.3

3.2

0.8 to 1.1

φ10

10.0

7.9

11.0

10.3

10.3

4.6

0.8 to 1.1

φ10

10.0

9.9

11.0

10.3

10.3

4.6

0.8 to 1.1

φ10

10.0

12.6

11.0

10.3

10.3

4.6

0.8 to 1.1

(mm)

Dimension table in next page.

CF

CJ

Low ESR

Higher Capacitance

Long Life

CS

CG

Higher

Capacitance,

CAT.8100C
