SERIES:

VLED15 │ DESCRIPTION: LED DRIVER

MODEL

output current

output wattage

efficiency

min

(Vdc)

max

(Vdc)

min

(A)

max

(A)

max

(W)

max

(%)

VLED15-120-350

24

48

0

350

16.8

80

VLED15-120-480

10

13.5

0

480

6.5

80

VLED15-120-600

8

12

0

600

7.2

80

VLED15-120-700

16

24

0

700

16.8

80

VLED15-120-800

8

12

0

800

9.6

80

VLED15-120-900

10

16

0

900

14.4

80

VLED15-120-900L

8

12

0

900

10.8

80

VLED15-120-1000

10

16

0

1,000

16

80

VLED15-120-1200

10

14.1

0

1,200

16.92

80

VLED15-120-1250

8

12

0

1,250

15

80

8

11.5

0

1,400

16.1

80

VLED15-120-1500

5

10

0

1,500

15

80

VLED15-230-350

24

48

0

350

16.8

80

VLED15-230-480

10

13.5

0

480

6.5

80

VLED15-230-600

8

12

0

600

7.2

80

VLED15-230-700

16

24

0

700

16.8

80

VLED15-230-800

8

12

0

800

9.6

80

VLED15-230-900

10

16

0

900

14.4

80

VLED15-230-900L

8

12

0

900

10.8

80

VLED15-230-1000

10

16

0

1,000

16

80

VLED15-230-1200

10

14.1

0

1,200

16.92

80

VLED15-230-1250

8

12

0

1,250

15

80

8

11.5

0

1,400

16.1

80

VLED15-230-1500

5

10

0

1,500

15

80

Note:

1. Total LED forward voltage must be within these ratings under all conditions including dimming

2. 80°C maximum case rating

3. Ripple Current: <40% (p-p) of maximum Output Current with no dimming

FEATURES

• constant current

• high efficiency

• 90~135 Vac and 176~265 Vac input range available

• 0.35~1.5 A output current

• operates with industry standard dimmers

• compact encapsulated assembly

• active power factor correction

• over voltage, over current, over temperature protection max.,

short circuit protection: auto recovery

• high temperature operation (up to 90°C case)

• UL approved, ENEC approved, CE Mark

• long life > 50,000 hours
