USER DIRECTION OF FEED

200

(7.874)

NO COMPONENT

NO COMPONENT

COMPONENTS

11200

(440.945)

400

(15.748)

START

4.0 ± 0.1

(.157 ± 0.04)

16.0 ± 0.1

(.630 ± .004)

4.4 ± 0.1

(.173 ± .004)

5.3 ± 0.1

(.153 ± .004)

0.4 ± 0.05

(.016 ± .002)

24.0 ± 0.3

(.945 ± .012)

13.2 ± 0.1

(.520 ± .004)

11.5 ± 0.1

(.453 ± .004)

1.55 ± 0.05

(.061 ± .002)

DIA.

1.5

(.059)

MIN.

END

101

101

101

10.4 ± 0.1

(.409 ± .004)

SRF0504 Series - Line Filter

Packaging Specifications

QTY: 600 PCS. PER REEL

REV. 12/12

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

SDR1005 Series - SMD Power Inductors

DIMENSIONS:

MM

(INCHES)

EMBOSSED

CARRIER

EMBOSSED

CAVITY

0.10

(.004)

THICKNESS

MAX.

24 0

Soldering Profile

26

(1.02)

30.4

(1.20)

2.0 ± 0.5

(.079 ± .020)

50.0

(1.969)

330

(12.99)

DIA.

13.0 ± 0.5

(.512 ± .020)

DIA.

13.0 ± 0.5

(.512 ± .020)

DIA.

21.0 ± 0.8

(.827 ± .031)

Peak Temperature:

245 °C max.

Max. Peak Temperature: -5 °C, 30 sec. max.

Max. Time Above 217 °C: 60 ~ 150 sec. max.

250

0

50

50

200

150

100

+4.0 °C / sec. max.

150~200 °C / 60~120 sec.

+3.0 °C / sec. max.

-(1.0~5.0) °C / sec. max.

Temperature

Rising Area

Preheat Area

Reflow Area

Forced Cooling Area

200

Time (Seconds)

100

150

60 ~ 150 sec.

60 sec. max.

Peak Temp: 245 °C

217 °C

60 ~ 120 sec.

250
