TECHNICAL DATA SHEET

75 Ohm BNC Male Connector Crimp/Solder Attachment For RG179-DS, 179DT

Configuration

Connector

BNC Male

Connector Interface Type

RG179-DS,179DT

Cable Attachment Method (Shield/Contact)

Crimp/Solder

Body Style

Straight

Electrical Specifications

Impedance, Ohms

75

Mechanical Specifications

Size

Length, in [mm]

1.265 [32.13]

Width/Dia., in [mm]

0.57 [14.48]

.

Weight, lbs [g]

0.02 [9.07]

Connector

Type

BNC Male

Contact Material and Plating

Brass, Gold

Coupling Nut Material and Plating

Brass, Black Chrome

Body Material and Plating

Brass, Nickel

Dielectric Type

Teflon

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

75 Ohm BNC Male Connector Crimp/Solder Attachment For RG179-DS, 179DT from Pasternack Enterprises has same day

shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain a 99% availability and

are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 75 Ohm BNC Male Connector Crimp/Solder Attachment For RG179-DS, 179DT PE44629

URL: http://www.pasternack.com/bnc-male-standard-rg179-ds-179dt-connector-pe44629-p.aspx

PE44629

PE44629 REV 01
