ADG779

Rev. A | Page 5 of 12

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

−0.3 V to +7 V

Analog, Digital Inputs1

whichever occurs first

Peak Current, S or D

100 mA (pulsed at 1 ms,

10% duty cycle max)

Continuous Current, S or D

30 mA

Operating Temperature Range

Industrial (B Version)

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

SC70 Package, Power Dissipation

315 mW

332°C/W

120°C/W

Lead Temperature, Soldering

Vapor Phase (60 sec)

215°C

Infrared (15 sec)

220°C

Reflow Soldering (Pb-free)

Peak Temperature

260 (+0/−5)°C

Time at Peak Temperature

10 sec to 40 sec

limited to the maximum ratings given.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 4. Truth Table

ADG779 IN

Switch S1

Switch S2

0

On

Off

1

Off

On

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
