Preliminary Data Sheet

September 2001

High-Voltage Ringing SLIC for VoIP Applications

L9500A

30

Agere Systems Inc.

48-Pin MLCC, JEDEC MO-220 VKKD-2

Dimensions are in millimeters.

Notes: The dimensions in this outline diagram are intended for informational purposes only. For detailed schemat-

ics to assist your design efforts, please contact your Agere Sales Representative.

0195a

INDEX AREA

7.00

3.50

SEATING PLANE

0.08

0.20 REF

DETAIL A

7.00

5.00/5.25

3.50

11 SPACES @

0.50 = 5.50

0.50 BSC

0.18/0.30

0.02/0.05

1.00 MAX

0.23

0.30/0.50

1

3

2

(7.00/2 x 7.00/2)

PIN #1

IDENTIFIER ZONE

TOP VIEW

SIDE VIEW

DETAIL B

0.23

0.18

0.18

BOTTOM VIEW

2.50/2.625

EXPOSED PAD

DETAIL B

0.50 BSC

DETAIL A

VIEW FOR EVEN TERMINAL/SIDE
