TECHNICAL DATA SHEET

N Male Connector Clamp/Solder (Captive Contact) Attachment

For RG213, RG214, RG8, RG9, RG11, RG225, RG393

Configuration

Connector

N Male

Connector Specification

MIL-STD-348A

Connector Interface Type

RG213,RG214,RG8,RG9,RG11,RG225,RG393

Cable Attachment Method (Shield/Contact)

Clamp/Solder (Captive Contact)

Body Style

Straight

Electrical Specifications

Frequency Range, GHz

DC to 11

Impedance, Ohms

50

Maximum VSWR

1.3:1

Maximum Operating Voltage, Volts

1,000

Dielectric Withstanding Voltage, Vrms

2,500

Mechanical Specifications

Temperature

Operating Range, deg C

-65 to +165

Size

Length, in [mm]

1.51 [38.35]

Width/Dia., in [mm]

0.827 [21]

Weight, lbs [g]

0.123 [55.79]

Connector

Type

N Male

Contact Material and Plating

Brass, Gold

Contact Plating Specification

30µ in. minimum

Body Material and Plating

Brass, Nickel

Body Plating Specification

100µ in. minimum

Dielectric Type

Teflon

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

N Male Connector Clamp/Solder (Captive Contact) Attachment For RG213, RG214, RG8, RG9, RG11, RG225, RG393 from

Pasternack Enterprises has same day shipment for domestic and International orders. We maintain 99% availability of the

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Male Connector Clamp/Solder (Captive Contact) Attachment For RG213, RG214, RG8,

RG9, RG11, RG225, RG393 PE4132
