SRI2K

Data transfer

Doc ID 15779 Rev 3

13/45

3.4

CRC

The 16-bit CRC used by the SRI2K is generated in compliance with the ISO14443 Type B

recommendation. For further information, please see Appendix A. The initial register

contents are all 1s: FFFFh.

The two-byte CRC is present in every request and in every answer frame, before the EOF.

The CRC is calculated on all the bytes between SOF (not included) and the CRC field.

Upon reception of a request from a reader, the SRI2K verifies that the CRC value is valid. If

it is invalid, the SRI2K discards the frame and does not answer the reader.

Upon reception of an answer from the SRI2K, the reader should verify the validity of the

CRC. In case of error, the actions to be taken are the reader designer’s responsibility.

The CRC is transmitted with the least significant byte first and each byte is transmitted with

the least significant bit first.

Figure 11.

CRC transmission rules

CRC 16 (8 bits)

LSbit

MSbit

LSbit

MSbit

LSByte

MSByte

ai07667
