150 W

TMP708

VCC

GND

HYST

SET

OT

Microprocessor

VCC

GND

R

SET

470 kW

0.1 F

m

2.7 V to 5.5 V

TMP708

www.ti.com

SBOS585A

– DECEMBER 2011 – REVISED FEBRUARY 2012

Resistor-Programmable Temperature Switch in SOT Package

Check for Samples: TMP708

1

FEATURES

APPLICATIONS

2

•

Threshold Accuracy:

•

Computers (Laptops and Desktops)

– ±0.5°C Typical

•

Servers

– ±3°C Maximum (+60°C to +100°C)

•

Industrial and Medical Equipment

•

Temperature Threshold Set By 1% External

•

Storage Area Networks

Resistor

•

Automotive

•

Low Quiescent Current: 40

μA Typical

DESCRIPTION

•

Open-Drain, Active-Low Output Stage

The

TMP708

is

a

fully-integrated,

resistor-

•

Pin-Selectable 10

°C or 30°C Hysteresis

programmable temperature switch with a temperature

•

threshold that is set by just one external resistor

•

Supply Range: 2.7 V to 5.5 V

within its entire operating range. The TMP708

provides an open-drain, active-low output and has a

•

Package: 5-Pin SOT23

2.7 V to 5.5 V supply voltage range.

The temperature threshold accuracy is typically

±0.5°C with a maximum of ±3°C (+60°C to +100°C).

The quiescent current consumption is typically 40

μA.

Hysteresis is pin-selectable to 10

°C or 30°C.

The TMP708 is available in a 5-pin SOT23 package.

TYPICAL APPLICATION

1
