SSM2932

Data Sheet

Rev. 0 | Page 10 of 16

250

200

150

100

020

TOTAL OUTPUT POWER (mW)

Figure 21. Power Consumption vs. Output Power, PVDD = 3.0 V, RL = 32 Ω

140

120

100

020

TOTAL OUTPUT POWER (mW)

Figure 22. Power Dissipation vs. Output Power, PVDD = 3.0 V, RL = 32 Ω

100

LOAD RESISTANCE (Ω)

PVDD = 2.5V

PVDD = 3.3V

Figure 23. Maximum Output Power per Channel vs. Load Resistance,

Flying Capacitor = 1 μF, THD + N = 1%

350

300

250

200

100

150

020

TOTAL OUTPUT POWER (mW)

Figure 24. Power Consumption vs. Output Power, PVDD = 3.0 V, RL = 16 Ω

250

200

150

100

020

TOTAL OUTPUT POWER (mW)

Figure 25. Power Dissipation vs. Output Power, PVDD = 3.0 V, RL = 16 Ω

1.72

1.70

1.68

1.66

1.64

1.62

1.60

2.5

2.7

2.9

3.1

3.3

3.5

SUPPLY VOLTAGE (V)

RL = 32Ω

RL = 16Ω

Figure 26. Quiescent Current vs. Supply Voltage
