ADL5336

Data Sheet

Rev. B | Page 8 of 32

TYPICAL PERFORMANCE CHARACTERISTICS

VS = 5 V, TA = 25°C, ZS = 200 Ω, ZL VGA1 = 200 Ω, ZL VGA2 = 100 Ω, RF input = −20 dBm at 140 MHz, unless otherwise noted. Gain code =

11, VGAIN = 1 V, setpoint code = 000, MODE = 5 V (VGA mode) for both amplifiers, unless otherwise noted.

Figure 5. Gain vs. Frequency over VGAIN at Gain Code 11 for VGA1

Figure 6. Gain vs. Frequency over Gain Code at VGAIN = 0.5 V for VGA1

Figure 7. Gain vs. VGAIN over Frequency at Gain Code 11 for VGA1

Figure 8. Gain vs. Frequency over VGAIN at Gain Code 11 for VGA2

Figure 9. Gain vs. Frequency over Gain Code at VGAIN = 0.5 V for VGA2

Figure 10. Gain vs. VGAIN over Frequency at Gain Code 11 for VGA2

–40

–30

–20

–10

10M

100M

FREQUENCY (Hz)

0mV

200mV

400mV

600mV

800mV

1000mV

GAIN1

–25

–20

–15

–10

–5

100M

FREQUENCY (Hz)

GAIN CODE 00

GAIN CODE 01

GAIN CODE 10

GAIN CODE 11

–2.0

–1.5

–1.0

–0.5

0.5

1.0

1.5

2.0

–15

–10

–5

100

200

300

400

500

600

700

800

900

1000

GAIN1 (mV)

140MHz

350MHz

140MHz

350MHz

–50

–40

–30

–20

–10

10M

100M

FREQUENCY (Hz)

0mV

200mV

400mV

600mV

800mV

1000mV

GAIN2

–30

–25

–20

–15

–10

–5

10M

100M

FREQUENCY (Hz)

GAIN CODE 00

GAIN CODE 01

GAIN CODE 10

GAIN CODE 11

–4

–3

–2

–1

100

200

300

400

500

600

700

800

900

1000

GAIN1 (mV)

–5

140MHz

350MHz

140MHz

350MHz
