ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VPOS

+6 V

VNEG

−6 V

Input Current to INUM, IDEN

20 mA

Thermal Data, 2-Layer JEDEC Board No Air

Flow (Exposed Pad Soldered to PCB)

θJA

61.6°C/W

θJC

1.2°C/W

Maximum Power Dissipation (Exposed

Pad Soldered to PC Board)

0.6 W

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
