V2267

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 8

www.unisonic.com.tw

QW-R124-006.C

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

Power Dissipation

DIP-8

500

SOP-8

350

MSOP-8

300

TSSOP-8

250

Operating Temperature

TOPR

-40 ~ +85

°С

Storage Temperature

TSTG

-40 ~ +125

°С

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (VCC=5V, TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Input Clamp Voltage

VCL

Measuring at TP1(TP2) No signal

1.79

1.91

2.03

Operating Current

ICC

No signal

14.0

18.2

Voltage Gain

VOUT1/VIN1, VOUT2/VIN2

at VIN1(VIN2) =1MHz, 1VP-P, Sinewave

5.7

6.2

6.7

Frequency Characteristic

VIN=1Vp-p, Sinewave, 7MHz/1MHz

±1.0

Crosstalk

VOUT2/VOUT1 at VIN1 = 4.43MHz, 1VP-P, VIN2=Gnd,

Sinewave

VOUT1/VOUT2 at VIN2 =4.43MHz, 1VP-P,VIN1=Gnd,

Sinewave

-70

Gain Offset

GCH

VIN=1MHz, 1VP-P, GV1 = VOUT1/VIN1,

GV2 = VOUT2/VIN2, GCH = GV1-GV2

±0.5

SAG Terminal Gain

GSAG

Differential Gain

GDIFF

VIN1=1VP-P, Staircase

Measuring VOUT3 at VIN1 = Staircase Signal

1.0

3.0

Differential Phase

VIN1=1VP-P, Staircase

Measuring VOUT3 at VIN1 = Staircase Signal

1.0

3.0

deg
