DTA143X

PNP SILICON TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R206-078.E

ABSOLUTE MAXIMUM RATINGS (TA=25°C)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-50

Input Voltage

-20 ~ +7

Output Current

-100

IC(MAX.)

-100

Power Dissipation

SOT-23/SOT-323/SOT-523

300

TO-92

625

TO-92SP

550

Junction Temperature

150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (TA =25°C)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Input Voltage

VI(OFF)

VCC=−5V, IO=−100μA

-0.3

VI(ON)

VO=−0.3V, IO=−20mA

-2.5

Output Voltage

VO(ON)

IO/II=−10mA/−0.5mA

-0.1

-0.3

Input Current

VI=−5V

-1.8

Output Current

IO(OFF)

VCC=−50V, VI=0V

-0.5

μA

DC Current Gain

VO=−5V, IO=−10mA

Input Resistance

3.29

4.7

6.11

KΩ

Resistance Ratio

R2/R1

1.7

2.1

2.6

Transition Frequency

VCE=−10V, IE=5mA, f=100MHz (Note)

250

MHz

Note: Transition frequency of the device
