UNISONIC TECHNOLOGIES CO., LTD

UT5003

Power MOSFET

www.unisonic.com.tw

1 of 8

QW-R502-167.B

DUAL ENHANCEMENT MODE

(N-CHANNEL/P-CHANNEL)

DESCRIPTION

The UT5003 can provide excellent RDS (ON) and low gate

charge by using UTC’s advanced trench technology. This device

is suitable for use as a load switch or in PWM applications.

FEATURES

* N-Channel: 30V/7A

RDS(ON) = 27.5mΩ @ VGS =10V

RDS(ON) = 40mΩ @ VGS= 4.5V

* P-Channel: -30V/-5A

RDS(ON) = 45mΩ @ VGS= -10V

RDS(ON) = 80mΩ @ VGS= -4.5V

* Super high dense cell design

* Reliable and rugged

SYMBOL

ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

Package

Packing

UT5003L-S08-R

UT5003G-S08-R

SOP-8

Tape Reel
