3 / 5 page ![]() UT4410 Power MOSFET DJL UNISONICTECHNOLOGIESCO.,LTD 3 of 5 www.unisonic.com.tw QW-R502-238.A ABSOLUTE MAXIMUM RATINGS (TA =25℃, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 30 V Gate-Source Voltage VGSS ±20 V Continuous Drain Current ID 11.6 A Pulsed Drain Current IDM 46.4 A Power Dissipation PD 3.6 W Junction Temperature TJ -55 ~ +150 ℃ Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL MIN TYP MAX UNIT Junction to Ambient θJA 60 ℃ /W Notes: The device mounted on 1in 2 FR4 board with 2 oz copper ELECTRICAL CHARACTERISTICS (TA =25℃, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Leakage Current IDSS VDS=30V, VGS=0V 1 µA Gate-Source Leakage Current IGSS VGS=±20V, VDS=0V ±100 nA ON CHARACTERISTICS Gate-Threshold Voltage VGS(TH) VDS=VGS, ID=250µA 1.3 1.6 3.0 V VGS=10V, ID=10A 12 18 Static Drain–Source On–Resistance(Note) RDS(ON) VGS=4.5V, ID=8A 17 20 mΩ On-State Drain Current(Note) ID(ON) VDS= 5V, VGS=10V 20 A DYNAMIC PARAMETERS Input Capacitance CISS 700 800 pF Output Capacitance COSS 120 pF Reverse Transfer Capacitance CRSS VDS=15V, VGS=0V, f=1.0MHz 35 pF Gate Resistance RG VDS=0V, VGS =0V, f=1.0MHz 0.9 Ω SWITCHING PARAMETERS Turn-ON Delay Time tD(ON) 14 32 ns Turn-ON Rise Time tR 12 64 ns Turn-OFF Delay Time tD(OFF) 43 280 ns Turn-OFF Fall-Time tF VDD=25V, ID=1A, RL=25Ω VGEN=10V, RG=6Ω 4 192 ns Total Gate Charge QG VDS=15V, VGS=4.5V, ID=10A 11 15 nC Total Gate Charge QGT 20 26 nC Gate Source Charge QGS 5 nC Gate Drain Charge QGD VDS=15V, VGS=10V, ID=10A 4.9 nC SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Drain-Source Diode Forward Voltage VSD IS=2.3 A,VGS=0V 0.7 1.1 V Note: Pulse test; pulse width ≤ 300us, duty cycle≤ 2% |
|
|
