2 / 3 page ![]() UT136N03 Preliminary Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 3 www.unisonic.com.tw QW-R502-459.a ABSOLUTE MAXIMUM RATINGS (TC =25°C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 30 V Gate-Source Voltage VGSS ±20 V Continuous Drain Current ID 136 A Pulsed Drain Current (Note1) IDM 400 A Single Pulsed Avalanche Energy (Note4) EAS 875 mJ Power Dissipation PD 100 W Junction Temperature TJ +175 °C Storage Temperature TSTG -55 ~ +175 °C Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient θJA 62.5 °C/W Junction to Case θJC 1.4 °C/W ELECTRICAL CHARACTERISTICS (TJ =25°C, unless otherwise noted) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS =0 V, ID =250 µA 30 V Drain-Source Leakage Current IDSS VDS=30 V,VGS =0 V 1 µA Gate-Source Leakage Current IGSS VDS =0 V, VGS = ±20 V ±100 nA ON CHARACTERISTICS (Note2) Gate Threshold Voltage VGS(TH) VDS =VGS, ID =250 µA 1 3 V VGS =10 V, ID =40 A 3.6 4.5 Static Drain-Source On-Resistance RDS(ON) VGS =4.5 V, ID =40 A 5.6 mΩ DYNAMIC PARAMETERS (Note3) Input Capacitance CISS 3800 Output Capacitance COSS 800 Reverse Transfer Capacitance CRSS VDS =15V, VGS =0V, f=1.0MHz 600 pF SWITCHING PARAMETERS (Note3) Total Gate Charge QG 60 72 Gate Source Charge QGS 20.8 Gate Drain Charge QGD VDS =15V, VGS =5V, ID =16A 22 nC Turn-ON Delay Time tD(ON) 25.7 50 Turn-ON Rise Time tR 10 20 Turn-OFF Delay Time tD(OFF) 128 200 Turn-OFF Fall-Time tF VDD=15V, ID =1A, RGEN =6Ω VGS =10 V 34 70 ns SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Drain-Source Diode Forward Voltage VSD IS=20 A,VGS=0 V 1.5 V Drain-Source Diode Forward Current IS 90 A Note : 1. Pulse width limited by maximum junction temperature 2. Pulse Test : Pulse Width < 300μs, Duty Cycle < 2%. 3. Guaranteed by design, not subject to production testing. 4. L = 0.5mH, IAS = 35A, VDD = 25V, RG = 25Ω, Starting TJ = 25°C. |
|
|
