US201/A/B/C

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 7

www.unisonic.com.tw

QW-R502-302.H

ABSOLUTE MAXIMUM RATING(Ta=25°С, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

6.5

+2 ~ +5.5 (Note 2)

Input/Output Pins

VCTL

-0.3~ +6.5

0 ~ +5.5 (Note 2)

V FLG

FLG

6.5

Junction Temperature

150

℃

-20 ~ +100 (Note 2)

℃

Storage Temperature

TSTG

-65 ~ +150

℃

Notes:1.

Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

The device is not guaranteed to function when it’s beyond its operating conditions.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

260

℃/W

Junction to Case

θJC

℃/W

ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

ENABLE INPUT

CTL Threshold

Low

VIL

VIN=2V~5.5V, Switch OFF

0.8

High

VIH

VIN=2V~5.5V, Switch ON

2.0

CTL Input Current

II(CTL)

VCTL=0V~5.5V

0.01

µA

UNDER VOLTAGE LOCK

Under-Voltage Lockout

VUVLO

VIN increasing

US201/ US201A

1.3

US201B/ US201C

2.5

Under-Voltage Hysteresis

∆VUVLO

VIN decreasing

0.1

SUPPLY CURRENT

Supply Current

ISW(ON)

Switch on, VOUT=OPEN

µA

ISW(OFF)

Switch off, VOUT=OPEN

0.1

µA

Output Leakage Current

IO(LEAK)

VCTL=0V, RLOAD=0Ω

0.5

µA

CURRENT LIMIT

Current Limit

ILIMIT

US201

0.6

0.8

1.1

US201A

1.1

1.5

1.9

US201B

1.3

1.7

2.1

US201C

1.5

2.0

2.4

Short Circuit Fold-Back Current

ISC(FB)

VOUT=0V, measured prior

to thermal shutdown

US201

0.8

US201A

1.0

US201B

1.0

US201C

1.3
