ABSOLUTE MAXIMUM RATINGS

OPERATING CHARACTERISTICS

RI-TRP-R9VS, RI-TRP-W9VS

over operating free-air temperature range (unless otherwise noted)

RI-TRP-R9VS, RI-TRP-W9VS

Operating Temperature

–25 to 70°C

Storage Temperature

–25 to 85°C

over operating free-air temperature range (unless otherwise noted)

RI-TRP-R9VS

RI-TRP-W9VS

Functionality

Read only

Read/write

Memory (Bits)

64

80

Memory (Pages)

1

1

Operating Frequency

134.2 kHz

Modulation

FSK (frequency shift keying) 134.2 kHz / 123.2 kHz

Transmission Principle

HDX (half duplex)

Power Source

Powered from the reader signal

Typical Reading Range

Typical Programming Range

—

30% of typical reading range

Typical Reading Time

70 ms

Typical Programming Time

—

309 ms

Typical Programming Cycles

—

100,000

Case Material

Polypropylene, black

Protection Class

IP 67

Mounting

With screws or rivets on aluminum, iron, or steel

EMC

Programmed code is not affected by normal electromagnetic interference or X-rays

Signal Penetration

Transponder can be read through virtually all non-metallic material

Mechanical Shock

IEC 68-2-27, Test Ea; 200 g, half sine, 3 ms, 3 axes, 6 shocks per axis

Vibration

IEC 68-2-6, Test Fc; 20 g, 20 - 500 Hz, 3 axes, 10 cycles per axis

Dimensions

102 mm ± 1 mm × 36 mm ± 1 mm × 16.5 mm ± 1 mm

Weight

43 g

(1)

Depending on RF regulation in country of use, the reader antenna configuration used, and the environmental conditions.
