ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

All Other Pins

V

Supply Voltage

6.5

V

520

mW

Junction Temperature

150

°C

Operating Temperature

-40 ~ +85

°C

Storage Temperature

-65 ~ +160

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

240

°C/W

ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Supplies

Supply Voltage Range (Note)

3

5.5

V

Supply Current

No load

0.5

0.7

mA

Total Power Dissipation

No load

0.25

0.35

mW

DC Characteristics

Input Offset Voltage

±15

±10

mV

Common Mode Voltage

Inferred from CMRR test

0

5

V

Input Bias Current

±1.5

±20

nA

Input Bias Current Offset

±1.5

±20

nA

Input Resistance

1000

MΩ

Open Loop Gain

85

95

dB

Maximum Output Current

55

±66

mA

Output Voltage Swing High

4.96

4.99

V

Output Voltage Swing Low

0.012 0.04

V

Power Supply Rejection Ratio

PSRR

45

70

dB

Common-Mode Rejection Ratio

CMRR

45

65

dB

AC Characteristics

Gain-Bandwidth Product

GBWP

Open-loop, No load

6.5

Slew-Rate

SR

5.23

V/μs

Phase Margin

PM

60

deg

Maximum Output Power

100

mA

Notes: Guaranteed by the Power-Supply Rejection Ratio (PSRR) test
