DTC144E

NPN SILICON TRANSISTOR

UNISONIC TECHNOLOGIES CO., LTD

2 of 3

www.unisonic.com.tw

QW-R206-050,F

ABSOLUTE MAXIMUM RATINGS (TA = 25°C)

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (TA= 25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Input Voltage

VIN(OFF)

VCC= 5V, IOUT=100μA

0.5

VIN(ON)

VOUT= 0.3V, IOUT= 20mA

Output Voltage

VOUT(ON) IOUT/IIN= 10mA / 0.5mA

0.1

0.3

Input Current

IIN

VIN= 5V

0.18

Output Current

IOUT(OFF) VCC= 50V , VIN=0V

0.5

μA

DC Current Gain

hFE

VOUT= 5V, IOUT= 5mA

Input Resistance

32.9

61.1

kΩ

Resistance Ratio

R2/R1

0.8

1.2

Transition Frequency

VCE= 10V, IE= -5mA, f=100MHz

250

MHz

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

Input Voltage

VIN

-10 ~ +40

Output Current

IOUT

IOUT(MAX)

100

Power Dissipation

TO-92SP

550

TO-92

625

SOT-523

150

SOT-23/SOT-323

200

Junction Temperature

+150

°C

Storage Temperature

TSTG

-55~+150

°C
