Actual Size

SERIES

Shielded Surface Mount Inductors

Physical Parameters

Inches

Millimeters

A

0.244 ± 0.012

6.2 ± 0.3

B

0.260 ± .012

6.6 ± 0.3

C

0.118 Max.

3.0 Max.

D

0.181 Ref. only

4.60 Ref. only

E

0.059 ± 0.007

1.5 ± 0.2

F

0.050 ± 0.007

1.27 ± 0.2

G

0.015 Ref. only

0.38 Ref. only

Mechanical Configuration Units designed for surface

mounting; ferrite core and ferrite sleeve

Operating temperature range –55°C to +125°C

Application Frequency Range

Values 1.2µH to 12µH to 1.0 MHz Min.

Values above 12µH to 300 kHz Min.

Current Rating at 25°C Ambient The maximum DC

current that will cause a 40°C maximum temperature rise

and where the inductance will not decrease by more than

10% from its zero DC value

Packaging Tape & reel (16mm):

13" reel, 1500 pieces max.; 7" reel not available

270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com

SPD62R

SERIES SPD62 FERRITE CORE & SLEEVE

-122M

-242M

-352M

-472M

-682M

-103M

-123M

-153M

-183M

-223M

-273M

-333M

-393M

-473M

-563M

-683M

-823M

-104M

-124M

-154M

-184M

-224M

-274M

-334M

3.50

2.80

2.50

2.00

1.80

1.40

1.30

1.20

1.10

1.00

0.94

0.82

0.78

0.70

0.68

0.56

0.50

0.41

0.39

0.37

0.35

0.32

0.29

0.22

0.08

0.10

0.12

0.15

0.17

0.18

0.20

0.30

0.35

0.40

0.45

0.50

0.70

0.75

0.85

1.20

1.45

1.60

1.70

1.80

2.10

2.20

3.00

3.30

100

100

100

100

100

100

100

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.2

2.4

3.5

4.7

6.8

10

12

15

18

22

27

33

39

47

56

68

82

100

120

150

180

220

270

330

*Complete part # must include series # PLUS the dash #

For surface finish information, refer to www.delevanfinishes.com

Marking For values lower than 10 H the R indicates a decimal point and

the remaining digits indicate the inductance in H. For values 10 H and

above, the first two digits indicate the inductance in H and the third digit

indicates the number of trailing zeros where a zero indicates that there are

no trailing zeros.

Example: SPD62R-122M (1.2 H)

1R2

Example: SPD62R-334M (330 H)

331

1/2009
