ADL5811
Rev. 0 | Page 23 of 28
LOW-PASS FILTER PROGRAMMING
The ADL5811 allows programmability for the low-pass filter
terminating the mixer output. This filter helps to block sum term
mixing products at the expense of some noise figure and gain
and can significantly increase input IP3. The ADL5811 defaults the
LPF setting to 0. Power conversion gain, input IP3, NF, and input
P1dB can be optimized, as shown in Figure 48 to Figure 51.
RF BALUN PROGRAMMING
The ADL5811 allows programmability for the RF balun by
allowing capacitance to be switched into both the input and the
output, which allows the balun to be tuned to cover the entire
frequency band (700 MHz to 2800 MHz). Under most circum-
stances, the input and output can be tuned together though
sometimes it may be advantageous for matching reasons to tune
them separately. The ADL5811 defaults the RFB setting to 0. Power
conversion gain, input IP3, NF, and input P1dB can be optimized,
as shown in Figure 44 to Figure 47.
