M692SDM

P e r f o r m a nc e Da t a sh ee t

Number

Name

I/O

Configuration

Description

1VIN

Input

Frequency control input.

2, 3, 5

GND

Ground

Power supply ground connection.

4

RF OUTPUT

Output

No internal terminator

Clock output. Single-ended.

6VCC

Power

Power supply connection, connect to +5.0 V.

Table 2: Pin Descriptions

Note 1: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the

device. These ratings are stress specifications only. Functional operation of product at these conditions

or any conditions beyond those listed in Recommended Conditions of Operation, DC Characteristics, or

AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods

may affect product reliability.

Symbol Parameter

Rating

Unit

V

I

Inputs

V

V

O

Outputs

V

V

CC

Power Supply Voltage

6.0

V

T

S

Storage Temperature

Table 3: Absolute Maximum Ratings

Symbol Parameter

Min

Typ

Max

Unit

V

CC

Positive Supply Voltage

4.875

5.0

5.125

V

+10

Table 4: Recommended Conditions of Operation
