TOROIDAL INDUCTOR

• RoHS Compliant Product

• Operating Temp: -55°C to +105°C

• Inductance test @ 1KHz, 0.1V

RMS

• I

• Add -V for Vertical Mount, -H for Horizontal Mount after

part number

Product performance is limited to specified parameter. Data is subject to change without prior notice.

P11T500-XXX

0547JW

Dimensions

Unless otherwise specified, all tolerances are:

inch: .XX : ± 0.008

.XXX : ±0.004

mm: X,X : ± 0,20 X,XX : ±0,10

ELECTRICAL SPECIFICATION @ 25°C

Part Number

L (µH)

Rated

R

DC

DIM.

DIM.

DIM.

±20%

Current

Max

A

B

C

P11T500-

(A)

( mW )

NOM.

NOM.

NOM.

R3

0.3

28.5

1.0

0.35

0.60

0.059

R5

0.5

24.7

1.2

0.35

0.60

0.059

R8

8

22.1

1.4

0.35

0.60

0.059

1R2

1.2

20.2

1.7

0.35

0.60

0.059

1R5

1.5

18.7

2.0

0.35

0.60

0.059

2R0

2

15.6

2.7

0.34

0.59

0.053

2R7

2.7

14.7

3.0

0.34

0.59

0.053

3R3

3.3

11.1

5.3

0.33

0.58

0.042

3R9

3.9

10.5

5.9

0.33

0.58

0.042

4R7

4.7

10.1

6.4

0.33

0.58

0.042

5R6

5.6

9.7

6.9

0.33

0.58

0.042

6R8

6.8

7.2

13.0

0.31

0.56

0.034

L=±15%

8R2

8.2

7.0

14.0

0.31

0.56

0.034

100

10

6.6

15.0

0.31

0.56

0.034

120

12

6.4

16.0

0.31

0.56

0.034

150

15

4.7

29.0

0.29

0.53

0.027

180

18

4.5

32.0

0.29

0.53

0.027

220

22

4.3

35.0

0.29

0.53

0.027

270

27

4.1

39.0

0.29

0.53

0.027

330

33

3.5

54.0

0.29

0.53

0.024

390

39

3.3

59.0

0.29

0.53

0.024

470

47

3.2

64.0

0.29

0.53

0.024

Mechanical

Schematic

P11T500 SERIES
