Echotel

® Model 300/301

Ultrasonic Non-Contact

Transmitter For Level, Volume,

and Open Channel Flow

DESCRIPTION

The Model 300/301 is a full-featured, powerful ultra-

sonic system for measurement of liquid level, volume,

or open channel flow. Available as an integral or

remote mounted transmitter, this extremely versatile

system is simple to install and calibrate. The non-

contact design means that it is not affected by changes

in specific gravity, viscosity, or conductivity.

FEATURES

• Isolated 4–20 mA output includes an active/passive

mode for loop power or device power.

• RS-485 with Modbus protocol allows bi-directional

communication with DCS or PLC.

• Two or four 10 amp SPDT gold flash relays provide

flexibility for most alarm and control schemes.

• 16-button keypad and two-line, 16-character LCD

alphanumeric display.

• Temperature compensation integral to ultrasonic

transducer.

• Output in units of level, volume, or open channel

flow.

• Most common flumes and weirs preprogrammed in

memory in addition to the Manning formula and a

custom table using either a linear or spline curve.

• Complete self-diagnostics checks all relays, outputs,

and system functionality.

• Class I, Div. 1, Groups B, C, and D on both the

transmitter and transducer.

• QuickCal mode allows complete system calibration

in 90 seconds.

• Powerful 38 kHz EchoMaster™ ultrasonic transducer

performs in difficult applications.

• Password protection prevents unwanted tampering

with configuration data.

APPLICATIONS

• Water and wastewater

• Slurries

• Viscous fluids

• Acids

• Oils

• Caustics
