ADP150

Rev. A | Page 9 of 20

–10

–20

–30

–40

–50

–60

–70

–80

–90

–100

100

10k

100k

10M

FREQUENCY (Hz)

IOUT = 100µA

IOUT = 1mA

IOUT = 10mA

IOUT = 100mA

IOUT = 150mA

VIN = VOUT + 0.5V

VRIPPLE = 50mV

CIN = COUT = 1µF

Figure 17. Power Supply Rejection Ratio (PSRR) vs. Frequency,

VOUT = 3.3 V, VIN = 3.8 V

–10

–20

–30

–40

–50

–60

–70

–80

–90

–100

100

10k

100k

10M

FREQUENCY (Hz)

VOUT = 1.8V, IOUT = 100µA

VOUT = 2.8V, IOUT = 100µA

VOUT = 3.3V, IOUT = 100µA

VOUT = 1.8V, IOUT = 150mA

VOUT = 2.8V, IOUT = 150mA

VOUT = 3.3V, IOUT = 150mA

VIN = VOUT + 0.5V

VRIPPLE = 50mV

CIN = COUT = 1µF

Figure 18. Power Supply Rejection Ratio (PSRR) vs. Frequency

Various Output Voltages and Load Currents

–10

–20

–30

–40

–50

–60

–70

–80

–90

–100

100

10k

100k

10M

FREQUENCY (Hz)

VIN = 3.8V, IOUT = 1mA

VIN = 4.3V, IOUT = 1mA

VIN = 5.3V, IOUT = 1mA

VIN = 3.8V, IOUT = 150mA

VIN = 4.3V, IOUT = 150mA

VIN = 5.3V, IOUT = 150mA

VRIPPLE = 50mV

CIN = COUT = 1µF

Figure 19. Power Supply Rejection Ratio (PSRR) vs. Frequency with

Various Headroom Voltages (VIN − VOUT), VOUT = 3.3 V

0.001

0.01

0.1

100

IOUT (mA)

VOUT = 3.3V

VOUT = 2.8V

VOUT = 1.8V

Figure 20. Output RMS Noise vs. Load Current (IOUT) and

Output Voltage (VOUT), VIN = 5 V, COUT = 1 µF

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VOUT = 1.8V

VOUT = 2.8V

VOUT = 3.3V

Figure 21. Output Noise Spectrum, VIN = 5 V, ILOAD = 10 mA, COUT = 1 μF

CH1 100mA

CH2 50mV

M40µs

A CH1

112mA

117.560µs

IOUT

1mA TO 150mA LOAD STEP

VOUT

VIN = 3.7V

VOUT = 3.3V

Figure 22. Load Transient Response, COUT = 1 µF
