LM393

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R104-002,J

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

18 or 36

Differential Input Voltage

VI(DIFF)

Input Voltage

VIN

-0.3 ~ +36

DIP-8

600

SOP-8

420

Power Dissipation

TSSOP-8

350

Operating Temperature Range

TOPR

-20 ~ +85

°C

Storage Temperature Range

TSTG

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS

(VCC=5.0V, Ta=25°C, All voltage referenced to GND unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Input Offset Voltage

VI(OFF)

VCM=0V toVCC-1.5V

VO(P)=1.4V, RS=0Ω

1.0

5.0

Output Saturation Voltage

VSAT

VI(-)>1V, VI(+)=0V, ISINK=4mA

160

400

Input Common Mode Voltage

VI(CM)

VCC=30V

VCC-1.5

Large Signal Voltage Gain

VCC=15V, RL≧15KΩ

200

V/mV

RL=∝, VCC=30V

0.8

2.5

Power Supply Current

ICC

RL=∝

0.6

1.0

Input Offset Current

II(OFF)

Input Bias Current

II(BIAS)

250

Output Sink Current

IO(SINK)

VI(-)>1V, VI(+)=0V, Vo(p)<1.5V

Vo(p)= 5V

0.1

Output Leakage Current

IO(LEAK)

VI(+)=1V, VI(-)=0

Vo(p)=30V

1.0

μA

Large Signal Response Time

VIN=TTL logic wing

VREF=1.4V, VRL=5V, RL=5.1kΩ

350

Response Time

VRL=5V,RL=5.1kΩ

1400
