3544L-S08-R datasheet(4/10 Pages) UTC

4 / 10 page

3544

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 10

www.unisonic.com.tw

QW-R107-040,C

ABSOLUTE MAXIMUM RATINGS (Ta=25°C)

PARAMETER

SYMBOL

RATINGS

UNIT

Applied Voltage

VMAX

7.0

450

Power Dissipation

Derate above 25°C

4.5

mW/°C

Operating Temperature

TOPR

-25 ~ +75

°C

Storage Temperature

TSTG

-55 ~ +125

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

RECOMMENDED OPERATING CONDITIONS (Ta=25°C)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

Power Supply Voltage

VCC

2.8

6.5

ELECTRICAL CHARACTERISTICS (Ta=25°C, VCC=5.0V, RL=32Ω, VIN= -6dBV, f=1kHz)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNIT

Mute Pin Control Voltage

VTM

0.3

0.7

1.6

Quiescent Current

VIN=0Vrms

Voltage Gain

Voltage Gain Difference Between Channels

△

Gv(DIFF)

-0.5

0.5

Total Harmonic Distortion

THD

BW=20~20kHz

0.02

0.1

Rated Output 1

Po1

RL=32Ω,THD<0.1%

Rated Output 2

Po2

RL=16Ω,THD<0.1%

Output Noise Voltage

BW=20~20kHz,Rg=0Ω

-93

-85

dBV

Channel Separation

Rg=0Ω

Mute Attenuation

ATT

Rg=0Ω

Ripple Rejection

fRR=100Hz, VRR= -20dBV
