1 / 1 page

C-10

GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912

Printed in U.S.A.

CAGE Code 06324

www.glenair.com

E-Mail: sales@glenair.com

A

B

C

D

E

F

G

Series 74

TYPE

D

EXTERNAL

SHIELD

MINIMUM

BEND RADIUS

LENGTH

(AS SPECIFIED IN FEET)

TUBING

SHIELD

B DIA

A DIA

TUBING FRACTIONAL

A INSIDE

B DIA

SIZE

SIZE REF

DIA MIN

MAX

06

3/16

.181

(4.6)

.370

(9.4)

09

9/32

.273

(6.9)

.464 (11.8)

10

5/16

.306

(7.8)

.500 (12.7)

12

3/8

.359

(9.1)

.560 (14.2)

14

7/16

.427 (10.8)

.621 (15.8)

16

1/2

.480 (12.2)

.700 (17.8)

20

5/8

.603 (15.3)

.820 (20.8)

24

3/4

.725 (18.4)

.980 (24.9)

28

7/8

.860 (21.8)

1.123 (28.5)

32

1

.970 (24.6)

1.276 (32.4)

40

1 1/4

1.205 (30.6)

1.589 (40.4)

48

1 1/2

1.437 (36.5)

1.882 (47.8)

56

1 3/4

1.688 (42.9)

2.132 (54.2)

64

2

1.937 (49.2)

2.382 (60.5)

MINIMUM

BEND RADIUS

.50 (12.7)

.75 (19.1)

.88 (22.4)

1.00 (25.4)

1.25 (31.8)

1.50 (38.1)

1.75 (44.5)

1.88 (47.8)

2.25 (57.2)

2.75 (69.9)

3.25 (82.6)

3.63 (92.2)

4.25 (108.0)

TABLE I: TUBING SIZE ORDER NUMBER AND DIMENSIONS

APPLICATION NOTES

Metric dimensions (mm) are

1.

in parentheses and are for

reference only.

Consult factory for thin-

2.

wall, close convolution

combination.

For PTFE maximum lengths

3.

- consult factory.

Consult factory for PEEK

4.

TM

min/max dimensions.

Class

1 - Standard Wall

2 - Thin Wall

2

Product Series

121 - Convoluted Tubing

121 - 101 - 1 - 1 - 16 B K T

Basic Part

Number

Tubing Size

(See Table I)

Convolution

1 - Standard

2 - Close

Color

B - Black

C - Natural

Material

K - PEEK

4

E - ETFE

F - FEP

P - PFA

T - PTFE

3

Shield

A - Composite AmberStrand®

C - Stainless Steel

N - Nickel/Copper

S - SnCuFe

T - Tin/Copper

121-101

Series 74 Helical Convoluted Tubing (AMS-T-81914)

Type D: Convoluted Tubing with Single External Shield
