MAX8564AEUB datasheet(2/15 Pages) MAXIM

2 / 15 page

±1%, Ultra-Low Output Voltage, Dual and Triple

Linear n-FET Controllers

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(VDD = VEN1 = VEN2 = VEN3 = 5V, VGND = 0V, TA = -40°C to +85°C, unless otherwise noted. Typical values are at TA = +25°C.) (Note 1)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional

operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to

absolute maximum rating conditions for extended periods may affect device reliability.

VDD to GND ............................................................-0.3V to +14V

DRV1, DRV2, DRV3, EN1, EN2,

EN3 to GND............................................-0.3V to (VDD + 0.3V)

FB1, FB2, FB3, POK1, POK2, POK3 to GND ...........-0.3V to +6V

Continuous Power Dissipation (TA = +70°C)

10-Pin µMAX (derate 5.6mW/°C above +70°C) ........444.4mW

16-Pin QSOP (derate 8.3mW/°C above +70°C)........666.7mW

Operating Temperature Range ...........................-40°C to +85°C

Junction Temperature ......................................................+150°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

GENERAL

VDD Voltage Range

4.5

13.2

VDD Undervoltage-Lockout Threshold

Rising, 200mV hysteresis (typ)

3.56

3.76

4.00

VEN_ = VDD = 12V (MAX8563)

930

1600

VDD Quiescent Current

VEN_ = VDD = 12V (MAX8564/MAX8564A)

660

1200

µA

VDD Shutdown Current

EN1 = EN2 = EN3 = GND, VDD = 12V

µA

LDOs

TA = 0°C to +85°C

0.494

0.5

0.504

FB_ Accuracy

TA = -40°C to +85°C

0.489

0.509

TA = +25°C

-100

+100

FB_ Input Bias Current

TA = +85°C

-8

MAX8563, MAX8564

100

DRV_ Soft-Start Charging Current

MAX8564A

µA

TA = 0°C to +85°C

DRV_ Max Sourcing Current

VFB_ = 0.45V

TA = -40°C to +85°C

TA = 0°C to +85°C

DRV_ Max Sinking Current

VFB_ = 0.6V

TA = -40°C to +85°C

1.8

VDD = 5V, VFB_ = 0.46V

4.7

DRV_ Max Voltage

VDD = 13.2V, VFB_ = 0.46V

8.0

10.9

FB_ Slow Short-Circuit Threshold

Measured at FB_ (falling)

400

FB_ Fast Short-Circuit Threshold

Measured at FB_ (falling)

300

Slow Short-Circuit Timer

µs

FB_ to DRV_ Transconductance

0.115

0.24

0.460

Mho

LOGIC

EN_ Input Low Level

0.7

EN_ Input High Level

1.3

TA = +25°C

-0.1

+0.1

EN_ Input Leakage Current

VEN_ = 0 and VDD,

VDD = 13.2V

TA = +85°C

0.001

µA
