9-20
RF2425
Rev A1 010228
9
Absolute Maximum Ratings
Parameter
Rating
Unit
Supply Voltage
0 to +8.0
VDC
Control Voltage
-1.0 to +6.0
VDC
Input RF Power
+33
dBm
Operating Ambient Temperature
-40 to +85
°C
Storage Temperature
-40 to +150
°C
Parameter
Specification
Unit
Condition
Min.
Typ.
Max.
Overall
T=25 °C, VDD=3.0V, Freq=900MHz
Frequency Range
DC to 2000
MHz
Insertion Loss
0.5
1
dB
Isolation
20
24
dB
CTRL= “Low;” IN1 to OUT2 crosstalk
20
24
dB
CTRL= “High;” IN2 to OUT1 crosstalk
“On” Input VSWR
1:1
Input of active channel
“Off” Input VSWR
100:1
Input of inactive channel (open circuit)
Output P1dB
+31
dBm
Control Logic
CTRL Logic “Low” Voltage
0
V
Channel 1 On, Channel 2 Off
CTRL Logic “High” Voltage
0.7
V
Channel 2 On, Channel 1 Off
Power Supply
Voltage
3
V
Specifications
1.5 to 6
V
Operating Limits
Current
1
2
mA
CTRL= “Low”
2
2.5
mA
CTRL= “High”
Caution! ESD sensitive device.
RF Micro Devices believes the furnished information is correct and accurate
at the time of this printing. However, RF Micro Devices reserves the right to
make changes to its products without notice. RF Micro Devices does not
assume responsibility for the use of the described product(s).
