Transient Voltage Suppressors

and ESD Protectors

PACDN042/43/44/45/46

Publication Order Number:

June 2010 Rev. 4

PACDN042/43/44/45/46/D

Features

•

Two, three, four, five, or six transient voltage

suppressors

•

Compact SMT package saves board space and

facilitates layout in space-critical applications

•

In-system ESD protection to

±20kV contact

discharge, per the IEC 61000-4-2 international

standard

•

Lead-free packaging

Applications

•

ESD protection of PC ports, including USB ports,

serial ports, parallel ports, IEEE1394 ports,

docking ports, proprietary ports, etc.

•

Protection of interface ports or IC pins which are

exposed to high ESD levels

Product Description

The

PACDN042/43/44/45/46 family of transient

voltage suppressor arrays provide a very high level of

protection for sensitive electronic components that

may be subjected to electrostatic discharge (ESD).

The PACDN042/43/44/45/46 devices safely dissipate

ESD

strikes,

exceeding

the

IEC

61000-4-2

International

Standard,

Level

4

(±8kV

contact

discharge). All pins are rated to withstand ±20kV

ESD

pulses

using

the IEC

61000-4-2 contact

discharge method. Using the MIL-STD-883D (Method

3015) specification for Human Body Model (HBM)

ESD, all pins are protected from contact discharges

of greater than ±30kV.
