STM6513
Pin descriptions
Doc ID 16490 Rev 2
9/29
Table 2.
tREC1 programmed by an ideal external capacitor
CtREC value (µF)
tREC1 (ms)
(1)(2)
1.
At 25 ° C. Example calculations based on an ideal capacitor. During application design and component
selection it should be considered that the current flowing into the external tREC programming capacitor
(CtREC) is on the order of 100 nA, therefore a low-leakage capacitor (ceramic or film capacitor) should be
used and placed as close as possible to the TRECADJ pin. Also an adequate low-leakage PCB
environment should be ensured to prevent tREC accuracy from being affected. A recommended minimum
value of CtREC is 0.001 µF.
2.
In case of repeated activations of the internal tREC timer, an interval of 10 ms min. is needed between tREC
intervals to fully discharge CtREC, so that the next tREC1 is as specified.
Closest common
CtREC value (µF)
Min.
Typ.
Max.
0.001
10
15
20
0.001
0.002
20
30
40
0.0022
0.01
100
150
200
0.01
0.014
140
210
280
0.015
0.028
280
420
560
0.027
0.056
560
840
1120
0.056
0.112
1120
1680
2240
0.12
