B229

sIn-line Adaptor

BIn-line Adaptor Panel Cutouts

Note1: Please use the non-radius surface in the panel hooking area.

Note2: Applicable panel thickness is 1.6 to 1.0mm (A slight backlash will occur in the thickness other than 1.6 and 1.2mm.)

Part Number

CL No.

Unit: mm

DF11- 4DEP-2A

DF11- 6DEP-2A

DF11- 8DEP-2A

DF11-10DEP-2A

DF11-12DEP-2A

DF11-14DEP-2A

DF11-16DEP-2A

DF11-18DEP-2A

DF11-20DEP-2A

DF11-22DEP-2A

DF11-24DEP-2A

DF11-26DEP-2A

DF11-28DEP-2A

DF11-30DEP-2A

DF11-32DEP-2A

543-0698-1

543-0699-4

543-0700-1

543-0701-4

543-0702-7

543-0703-0

543-0704-2

543-0705-5

543-0706-8

543-0707-0

543-0708-3

543-0709-6

543-0710-5

543-0711-8

543-0712-0

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

11.0

13.0

15.0

17.0

19.0

21.0

23.0

25.0

27.0

29.0

31.0

33.0

35.0

37.0

39.0

9.2

11.2

13.2

15.2

17.2

19.2

21.2

23.2

25.2

27.2

29.2

31.2

33.2

35.2

37.2

Number of Contacts

A

B

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

32.0

34.0

C

2.0

4.0

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

D

9.4

11.4

13.4

15.4

17.4

19.4

21.4

23.4

25.4

27.4

29.4

31.4

33.4

35.4

37.4

E

6.3

8.3

10.3

12.3

14.3

16.3

18.3

20.3

22.3

24.3

26.3

28.3

30.3

32.3

34.3

F

YES

RoHS

Note1: Delivered per bag unit (100 pcs.). Please order products per bag unit.

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.

All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
