HEAT SHRINK THIN WALL TUBING

Qualtek Electronics

Q2-R

SEMI-RIGID, MULTI-PURPOSE,

FLAME RETARDANT, POLYOLEFIN TUBING

SHRINK RATIO 2:1

Features/Applications

Outstanding physical, chemical and electrical properties. Widely

used for insulation of harnesses and connectors in such fields

as military, aerospace and fine electronic instruments. Resistant

to common fluids and solvents.

Technical Data

Size

(Inch)

Product Dimensions

As Supplied (mm)

Inside Diameter

(max.)

Standard Packaging

3/64

1/16

3/32

1/8

3/16

1/4

3/8

1/2

5/8

3/4

1

1.2

1.6

2.4

3.2

4.8

6.4

9.5

12.7

16.0

19.1

25.4

0.6

0.8

1.2

1.6

2.4

3.2

4.8

6.4

8.0

9.5

12.7

After Recovered (mm)

500

250

150

Wall Thickness

(min.)

Standard

Spool

*(SS)

(Feet)

100

50

Mini

Spool

*(MS)

(Feet)

0.4

0.5

0.6

0.7

0.9

Cut to

Length Pcs.

*(QB)

Qty per bag

40

36

32

28

24

20

16

14

12

8

6”

48”

25

5

Inside Diameter

(min.)

Property

a

t

a

D

l

a

c

i

p

y

T

d

o

h

t

e

M

t

s

e

T

ASTM D 2671

Self-extinguish in 30 sec.

ASTM D 2671

ASTM D 150

ASTM D 876

UL 224

ASTM D 570

SAE-AMS-DTL-23053/5

UL 224

Tensile Strength

Elongation at Break

Tensile Strength After Aging

(175°C, 168 hrs.)

Elongation After Aging (175°C, 168 hrs.)

Flammability

Heat Shock (250°C, 4 hrs.)

Cold Bend Test (-55°C, 4 hrs.)

Dielectric Strength

Volume Resistance

Copper Corrosion

Water Absorption

Chemical Resistance

Longitudinal Shrinkage

Eccentricity

16 MPa

500%

14 MPa

250%

Pass

No cracking

20 kV / mm

10

Ω.cm

Pass

0.15%

Pass

0 + 5%

< 30%

14

Operating temperature: -55°C to +135°C

Minimum shrink temperature: 90°C

Full recovery temperature: 130°C

Approval:

File No. E236137,

242540, 125°C, VW-1, 600V

Meets: SAE-AMS-DTL-23053/5 Class 1 & 3, Sony SS-00259

Standard color: Black, clear (Non-flame retardant)

RoHS Compliant

ISO-9001 Company

www.qualtekusa.com

Q2R-200D

Notes:

1.

* See Part Number Guide for standard packaging codes.

2.

Special sizes, packaging, colors and cut pieces are available upon request.
