ADL5358

Rev. 0 | Page 23 of

COMPLIANT TO JEDEC STANDARDS MO-220-VJJD-1

OUTLINE DIMENSIONS

3.85

3.70 SQ

3.55

TOP

VIEW

6.00

BSC SQ

5.75

BSC SQ

COPLANARITY

0.08

4.00

REF

0.75

0.60

0.50

BSC

PIN 1

INDICATOR

0.60 MAX

0.20 MIN

EXPOSED

PAD

(BOTTOM VIEW)

PIN 1

INDICATOR

0.35

0.28

0.23

0.20 REF

12° MAX

0.80 MAX

0.65 TYP

1.00

0.85

0.80

0.05 MAX

0.02 NOM

SEATING

PLANE

FORPROPERCONNECTIONOF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

Figure 57. 36-Lead Lead Frame Chip Scale Package [LFCSP_VQ]

6mm × 6 mm Body, Very Thin Quad (CP-36-1)

Dimensions shown in millimeters

ORDERING GUIDE

Model

Temperature Range

Package Description

Package Option

ADL5358ACPZ-R21

−40°C to +85°C

36-Lead LFCSP_VQ

CP-36-1

ADL5358ACPZ-R71

−40°C to +85°C

36-Lead LFCSP_VQ

CP-36-1

ADL5358-EVALZ1

Evaluation Board

1 Z = RoHS Compliant Part.
