UP1B-150-R datasheet(4/7 Pages) COOPER

tên linh kiện	UP1B-150-R

Giải thích chi tiết về linh kiện	Miniature surface mount design

PDF	7 Pages

Scroll/Zoom	100%

nhà sản xuất	COOPER [Cooper Bussmann, Inc.]

Trang chủ	http://www.cooperbussmann.com

Logo

4 / 7 page

14.3

10.7

5.1

1.5 Dia.

16.0

6.8

5.4

SECTION A-A

1.75

11.5

2.0

4.0

Direction of feed

Dimensions in millimeters.

UP2B Series

ACTUAL SIZE

UNI-PAC 2B

13.5

5.8

4.0

2.0

16.0

1.75

14.2

1.5 Dia.

7.7

SECTION A-A

28.4

Direction of feed

Dimensions in millimeters.

19.6

5.9

UP3B Series

15.3

11.1

4.0

2.0

24.0

1.75

14.2

1.5 Dia.

9.0

SECTION A-A

28.4

Direction of feed

Dimensions in millimeters.

22.3

7.2

UP4B Series

ACTUAL SIZE

UNI-PAC 3B

ACTUAL SIZE

UNI-PAC 4B

Packaging Information

6.4

2.3

4.0

2.0

12.0

1.75

7.5

1.5 Dia.

5.6

4.4

SECTION A-A

9.3

Direction of feed

Dimensions in millimeters.

UP1B Series

ACTUAL SIZE

UNI-PAC 1B

UNI-PAC™

Power Inductors

(Surface Mount)

Parts packaged on 13" Diameter reel,

900 parts per reel.

Parts packaged on 13" Diameter reel,

550 parts per reel.

Parts packaged on 13" Diameter reel,

450 parts per reel.

Parts packaged on 13" Diameter reel,

275 parts per reel.
