ADL5365

Rev. 0 | Page 11 of 24

VS = 5 V, IS = 95 mA, TA = 25°C, fRF = 1900 MHz, fLO = 1697 MHz, LO power = 0 dBm, RF power = 0 dBm, VGS0 = VGS1 = 0 V, and

ZO = 50 Ω, unless otherwise noted.

CONVERSION LOSS (dB)

6.8

7.0

7.2

7.4

7.6

7.8

100

MEAN: 7.33

STANDARD DEVIATION:0.232

Figure 23. Conversion Loss Distribution

INPUT IP3 (dBm)

100

MEAN: 36.11

STANDARD DEVIATION: 0.146

Figure 24. Input IP3 Distribution

100

7.9

8.0

8.1

8.2

8.3

8.4

8.5

8.6

8.7

NOISE FIGURE (dB)

MEAN = 8.29

STANDARD DEVIATION = 0.30

Figure 25. SSB Noise Figure Distribution

36.5

30.5

31.0

31.5

32.0

32.5

33.0

33.5

34.0

34.5

35.0

35.5

36.0

3.6

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.6

2.8

3.0

3.2

3.4

130

180

230

280

330

380

430

IF FREQUENCY (MHz)

Figure 26. IF Output Impedance (R Parallel, C Equivalent)

1700 1750 1800 1850 1900 1950 2000 2050 2100 2150 2200

RF FREQUENCY (MHz)

Figure 27. RF Port Return Loss, Fixed IF

1500 1550 1600 1650 1700 1750 1800 1850 1900 1950 2000

LO FREQUENCY (MHz)

SELECTED

UNSELECTED

Figure 28. LO Return Loss, Selected and Unselected
