DS22140A-page 9

MCP6L01/1R/1U/2/4

3.0

PIN DESCRIPTIONS

Descriptions of the pins are listed in Table 3-1.

TABLE 3-1:

PIN FUNCTION TABLE

3.1

Analog Outputs

The analog output pins (VOUT) are low-impedance

voltage sources.

3.2

Analog Inputs

The non-inverting and inverting inputs (VIN+, VIN–, …)

are high-impedance CMOS inputs with low bias

currents.

3.3

Power Supply Pins

The positive power supply (VDD) is 1.8V to 6.0V higher

than the negative power supply (VSS). For normal

operation, the other pins are between VSS and VDD.

Typically, these parts are used in a single (positive)

supply configuration. In this case, VSS is connected to

ground and VDD is connected to the supply. VDD will

need bypass capacitors.

MCP6L01

MCP6L01R

MCP6L01U

MCP6L02

MCP6L04

Symbol

Description

SC-70-5,

SOT-23-5

SOIC-8,

MSOP-8

SOIC-14,

TSSOP-14

VOUT, VOUTA

Output (op amp A)

VIN–, VINA–

Inverting Input (op amp A)

VIN+, VINA+

Non-inverting Input (op amp A)

VDD

Positive Power Supply

——

—

VINB+

Non-inverting Input (op amp B)

——

—

VINB–

Inverting Input (op amp B)

——

—

VOUTB

Output (op amp B)

——

VOUTC

Output (op amp C)

——

VINC–

Inverting Input (op amp C)

——

VINC+

Non-inverting Input (op amp C)

VSS

Negative Power Supply

——

VIND+

Non-inverting Input (op amp D)

——

VIND–

Inverting Input (op amp D)

——

VOUTD

Output (op amp D)

—

No Internal Connection
