5 / 20 page

ADN2872

Rev. 0 | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 3.

Parameter

Rating

VCC to GND

4. 2 V

IMODN, IMODP

−0.3 V to +4.8 V

PAVCAP, ERCAP, PAVSET, PAVREF, ERREF,

IBIAS, IBMON, IMMON, ALS, CCBIAS, RPAV,

ERSET, FAIL

−0.3 V to +3.9 V

DATAP, DATAN (Single-Ended Differential)

1.5 V

Junction Temperature (TJ max)

125°C

Operating Temperature Range, Industrial

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Power Dissipation (W)1

(TJ max − TA)/θJA

θJA Thermal Impedance2

48.6°C/W

θJC Thermal Impedance2

5.0°C/W

θJB Thermal Impedance2

28.4°C/W

1 Power consumption equations are provided in the Power Consumption

section.

2 θJA, θJB, and θJC are estimated when the part’s exposed pad is soldered on a

4-layer JEDEC board at zero airflow.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
