7 / 36 page

AD8363

Rev. 0 | Page 7 of 36

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage, VPOS

5.5 V

Input Average RF Power1

21 dBm

Equivalent Voltage, Sine Wave Input

2.51 V rms

Internal Power Dissipation

450 mW

θJC2

10.6°C/W

θJB2

35.3°C/W

θJA2

57.2°C/W

ΨJT2

1.0°C/W

ΨJB2

34°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

1 This is for long durations. Excursions above this level, with durations much

less than 1 second, are possible without damage.

2 No airflow with the exposed pad soldered to a 4-layer JEDEC board.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
