4 / 5 page

Unit：mm

CM02B Series

http://www.ddknet.co.jp

◎

Speciﬁcations and/or dimensions in this catalog are subject to change without notice. ◎ Your checking the latest speciﬁcations with our drawings would be highly appreciated.

○ Plug Receptacle with Metal Shell and Socket Contacts

○ Plug Insert Assembly with Socket Contacts for PCB Mount

2.5

3.5

Coding Pin

φ1.4

φ1.6±0.1

45°

4-φ1

3.2

PCB Mounting Dimension

P/N

CM02-8DP4SD(D1)-FG

Panel Thickness : 3mmMax.

28.5

6.3

Ｍ16×1Thread

Ｍ12×1Thread

Solder Cup Dia.1.3

+0.3

φ16

Panel Cutout Dimension

１

４

３

２

M12×1.0Thread

M16×1.0Thread

15.8

φ16

+0.1

（Panel Thickness : 3mm Max.）

Panel Cutout Dimension

Panel Thickness : 3mmMax.

28.5

6.3

Ｍ16×1Thread

Ｍ12×1Thread

Dip Tail Dia.φ2

Land

4-φ2.2

PCB Mounting Dimension

+0.3

φ1

Panel Cutout Dimiension

Soldering

Solder Dip

◎ CM01 Series

P/N

CM02-8DPR4S-CF

P/N

CM01-8DPRA-4SD-CF(01)

P/N

CM01-8DPRA-4S-CF(01)

・P C B Contacts

・Rear-mount conﬁguration

・P C B Contacts

・No shell

・Rear-mount conﬁguration
