MICROSPACE PC/104

Data subject to change without notice

AMD Processor 133MHz - MSM586SL

Feature

• AMD ELAN520 Processor

• 133MHz

• 32/64 Soldered DRAM

• COM1, COM2, COM3, COM4

• RTC and Watchdog Timer

• Single 5VDC Power Supply

• PC/104

Description

The MICROSPACE PC/104 MSM586SL does not

have video on board but otherwise has all the

usual interfaces provided by a standard PC with

additional features such as COM to DOC socket

and a programmable Watchdog timer. The serial

interfaces are available as RS422/485 or TTL.

The soldered SDRAM of the MSM586SL series

makes this computer board less sensitive to shock

and vibration.

Ordering Information

Item Codes

Part#

Description

MSM586SL-32

801344

Soldered 32MB SDRAM

Soldered 64MB SDRAM

Options

Assembly-Kit

710460

4 PC/104 Std. Stand-off posts, Hex Nuts, Screws

MSEIDECK

100-9637

44Pin to two 40Pin IDE cable

MSFC

801071

Adapter for regular floppy drive

MSM-CK

802605

Cable Kit, incl. cable for 1.8/2.5” hard drive

*More options may be available, please contact our Sales office *
