Advanced Digital Logic, Inc.; 4411 Morena Blvd., Suite 101; San Diego, CA 92117-4345

MICROSPACE PC/104

Data subject to change without notice

Feature Technical Specifications

FEATURES

FUNCTIONS

FUNCTION

REMARKS

Item code

MSM586SEG

MSM586SEL

MSM586SEN

CPU

ELAN520

ELAN520

ELAN520

2nd Level Cache

—

—

—

Performance (MHz)

133

133

133

DRAM Min-Max (MB)

SODIMM 32-128 SDRAM

SODIMM 32-128 SDRAM

SODIMM 32-128 SDRAM

Power Management

—

—

—

DiskOnChip Socket

yes

yes

yes

CompactFlash Socket

yes

yes

yes

Mouse, Keyboard

yes

yes

yes

Floppy Interface

yes

yes

yes

IDE Interface

yes (LB)

yes (LB)

yes (LB)

Onboard Flash

DOC/CF

DOC/CF

DOC/CF

COM1

RS232C (422/485 optional)

RS232C (422/485 optional)

RS232C (422/485 optional)

COM2

RS232C (422/485 optional)

RS232C (422/485 optional)

RS232C (422/485 optional)

COM3

RS232C (422/485 optional)

RS232C (422/485 optional)

RS232C (422/485 optional)

COM4

RS232C (422/485 optional)

RS232C (422/485 optional)

RS232C (422/485 optional)

LPT1

yes

yes

yes

USB

2 (V1.1)

2 (V1.1)

—

LAN

100/10BASE-T

100/10BASE-T

100/10BASE-T

Audio

—

—

—

Video Controller

ATI M1

—

—

Video Datapath

PCI

—

—

Video Memory

8MB

—

—

CRT Video

yes (VGA)

—

—

LCD Interface

24 Bit TFT 3V

—

—

LCD Resolution

1280 x 1024 x 256

—

—

Video Input

—

—

—

EEPROM Support

yes

yes

yes

Watchdog

yes

yes

yes

Power Normal (typ)

5V/~980mA (@64/133)

5V/~860mA (@32/133)

5V/~860mA (@32/133)

Power Suspend

—

—

—

Cooling Type

passive

passive

passive

Operating Temp.

-25°C to +70°C

-25°C to +70°C

-25°C to +70°C

Extended Temp.

-40°C to +85°C

-40°C to +85°C

-40°C to +85°C

Weight (gr)

100

100

80

MTBF

> 200’000 h

> 200’000 h

> 200’000 h
