4

OC-48 IR1/STM-16 S-16.1 SFP Transceiver

SP-48-IR1

20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486

9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213

LUMINENTOIC.COM

LUMNDS258-FEB1706

rev.A.1

Name of Field

Discription of Field

Address

Hex

ASCII

Vendor Name

SFPVendor name (ASCII)

20

4C

L

21

55

U

22

4D

M

23

49

I

24

4E

N

25

45

E

26

4E

N

27

54

T

28

4F

O

29

49

I

30

43

C

Vendor OUI

IEEE vendor OUI code for LuminentOIC Inc.

37

00

38

06

39

B5

Vendor PN

Part number in ASCII, e.g.

SP-48-IR1-CDA

40

53

S

41

50

P

42

34

4

43

38

8

44

49

I

45

52

R

46

31

1

47

43

C

48

44

D

49

41

A

EEPROM Serial ID

Pin

Function

Notes

1

TX GND

2

TX_FAULT

Open Collector

3

TX_DISABLE

Internally Pulled High

4

MOD_DEF2

Serial Data Input

5

MOD_DEF1

Serial Clock Input

6

MOD_DEF0

Internally Grounded

7

NC

Not Connected

8

LOS

Open Collector

9

RX Ground

10

RX Ground

11

RX Ground

12

RXD-

RX Data Negative

13

RXD+

RX Data Positive

14

RX GND

15

RX Power

16

TX Power

17

TX GND

18

TXD+

TX Data Positive

19

TXD-

TX Data Negative

20

TX GND

Pinout Definitions
